Ink Milling Machine Horizontal Pin Type Bead Sand Ball Pearl Grinding Mill for Mixing with Ce Certificate

Basic Info

Model NO.	EDW
Grinding Medium	Zirconia Beads
Applicable Industry	Coating, Paint, Ink, Pigment, Latex
Materials	Stainless Steel or Pure Zirconia
Usage	Industrial
Product Type	Paint
Transport Package	Wooden Case
Specification	EDW-5L----EDW-100L
Trademark	ELE
Origin	Shanghai, China
HS Code	8479820090
Production Capacity	200-2000L

Product Description

Horizontal Bead Mill (EDW)

Applications:

Middle, Low, High viscosity raw material, suitable for super fineness required Paints and printing inks, high quality car paint, pigments and dyes, ...A high abrasion nanoscale bead mill.



Features:

1. High abrasive resistance: Materials (zirconia, tungsten carbide, hard alloy etc. ) guarantee working life.
2. Dynamic fence booms: Discharge solve problems of slow discharge and grinding medium getting stuck.
3. German BURGMANN double mechanical end face seal, which can bear more than 10bar pressure.

4. Corrugated cooling system increase cooling area and improve cooling efficiency.

5. Grinding beads small to 0.2mm guarantee superfine grinding/milling.

6. Meet demands of continuous production&different viscosity& fineness.

7. Inner & outer double pins improve high wet grinding/milling efficiency.

8. Ex-proof (optional) & fault alarming.



Model	Chamber Volume (ml)	Main Power (kw)	Rotation Speed (rpm)	Capacity (L/h)	Dimension L*W*H (mm)	Weight (kg)
EDW-5	5	7.5	1440	200	1300*1050*450	650
EDW-15	15	18.5	1440	500	1600*1450*650	1200
EDW-20	20	22	1260	800	1600*1450*650	1350
EDW-30	30	37	1260	1200	1650*1550*750	1700
EDW-40	40	45	980	1500	1750*1650*850	2100
EDW-50	50	55	980	2000	1900*1850*850	2300
EDW-100	100	110	860	3000	2300*2150*950	3800
